git clone https://github.com/cubefs/compass.git
cd compass
mvn clean package -DskipTests -Pdist

mvn clean package -DskipTests -Pdist,spark  # 打包时 web 展示只有 spark 诊断页面

mvn clean package -DskipTests -Pdist,flink  # 打包时 web 展示只有 flink 诊断页面

cp dist/compass-v1.1.2.tar.gz docker/playground
cd docker/playground/
docker compose --profile dependencies up -d
docker compose --profile compass-demo up -d

# 启动所有模块
./bin/start_all.sh

# 停止所有模块
./bin/stop_all.sh

#!/bin/bash
# dolphinscheduler or airflow or custom
export SCHEDULER="dolphinscheduler"
export SPRING_PROFILES_ACTIVE="hadoop,${SCHEDULER}"

# Configuration for Scheduler MySQL, compass will subscribe data from scheduler database via canal
export SCHEDULER_MYSQL_ADDRESS="localhost:3306"
export SCHEDULER_MYSQL_DB="dolphinscheduler"
export SCHEDULER_DATASOURCE_URL="jdbc:mysql://${SCHEDULER_MYSQL_ADDRESS}/${SCHEDULER_MYSQL_DB}?useUnicode=true&characterEncoding=utf-8&serverTimezone=Asia/Shanghai"
export SCHEDULER_DATASOURCE_USERNAME=""
export SCHEDULER_DATASOURCE_PASSWORD=""

# Configuration for compass database (mysql or postgresql)
export DATASOURCE_TYPE="mysql"
export COMPASS_DATASOURCE_ADDRESS="localhost:3306"
export COMPASS_DATASOURCE_DB="compass"
export SPRING_DATASOURCE_URL="jdbc:${DATASOURCE_TYPE}://${COMPASS_DATASOURCE_ADDRESS}/${COMPASS_DATASOURCE_DB}"
export SPRING_DATASOURCE_USERNAME=""
export SPRING_DATASOURCE_PASSWORD=""

# Configuration for compass Kafka, used to subscribe data by canal and log queue, etc. (default version: 3.4.0)
export SPRING_KAFKA_BOOTSTRAPSERVERS="host1:port,host2:port"

# Configuration for compass redis, used to cache and log queue, etc. (cluster mode)
export SPRING_REDIS_CLUSTER_NODES="localhost:6379"
# Optional
export SPRING_REDIS_PASSWORD=""

# Zookeeper (cluster: 3.4.5, needed by canal)
export SPRING_ZOOKEEPER_NODES="localhost:2181"

# OpenSearch (default version: 1.3.12) or Elasticsearch (7.x~)
export SPRING_OPENSEARCH_NODES="localhost:9200"
# Optional
export SPRING_OPENSEARCH_USERNAME=""
# Optional
export SPRING_OPENSEARCH_PASSWORD=""
# Optional, needed by OpenSearch, keep empty if OpenSearch does not use truststore.
export SPRING_OPENSEARCH_TRUSTSTORE=""
# Optional, needed by OpenSearch, keep empty if OpenSearch does not use truststore.
export SPRING_OPENSEARCH_TRUSTSTOREPASSWORD=""

# Prometheus for flink, ignore it if you do not need flink.
export FLINK_PROMETHEUS_HOST="http://localhost:9090"
export FLINK_PROMETHEUS_TOKEN=""
export FLINK_PROMETHEUS_DATABASE=""

# Optional, needed by task-gpt module to get exception solution, ignore if you do not need it.
export CHATGPT_ENABLE=false
# Openai keys needed by enabling chatgpt, random access the key if there are multiple keys.
export CHATGPT_API_KEYS=sk-xxx1,sk-xxx2
# Optional, needed if setting proxy, or keep it empty.
export CHATGPT_PROXY="" # for example, https://proxy.ai
# chatgpt model
export CHATGPT_MODEL="gpt-3.5-turbo"
# chatgpt prompt
export CHATGPT_PROMPT="You are a senior expert in big data, teaching beginners. I will give you some anomalies and you will provide solutions to them."

# task-canal 模块配置
# 调度平台 MySQL 订阅账号，确定是否已开启 binlog
export CANAL_INSTANCE_MASTER_ADDRESS=${SCHEDULER_MYSQL_ADDRESS}
export CANAL_INSTANCE_DBUSERNAME=${SCHEDULER_DATASOURCE_USERNAME}
export CANAL_INSTANCE_DBPASSWORD=${SCHEDULER_DATASOURCE_PASSWORD}
# 需要订阅的库表配置过滤
if [ ${SCHEDULER} == "dolphinscheduler" ]; then
  export CANAL_INSTANCE_FILTER_REGEX="${SCHEDULER_MYSQL_DB}.t_ds_user,${SCHEDULER_MYSQL_DB}.t_ds_project,${SCHEDULER_MYSQL_DB}.t_ds_task_definition,${SCHEDULER_MYSQL_DB}.t_ds_task_instance,${SCHEDULER_MYSQL_DB}.t_ds_process_definition,${SCHEDULER_MYSQL_DB}.t_ds_process_instance,${SCHEDULER_MYSQL_DB}.t_ds_process_task_relation"
elif [ ${SCHEDULER} == "airflow" ]; then
  export CANAL_INSTANCE_FILTER_REGEX="${SCHEDULER_MYSQL_DB}.dag,${SCHEDULER_MYSQL_DB}.serialized_dag,${SCHEDULER_MYSQL_DB}.ab_user,${SCHEDULER_MYSQL_DB}.dag_run,${SCHEDULER_MYSQL_DB}.task_instance"
else
  export CANAL_INSTANCE_FILTER_REGEX=".*\..*"
fi

hadoop:
  # task-applicaiton & task-parser 模块配置依赖
  namenodes:
    - nameservices: logs-hdfs               # dfs.nameservices 属性值
      namenodesAddr: [ "machine1.example.com", "machine2.example.com" ]   # dfs.namenode.rpc-address.[nameservice ID].[name node ID] 属性值
      namenodes: ["nn1", "nn2"] # dfs.ha.namenodes.[nameservice ID] 属性值
      user: hdfs                            # 用户
      password:                             # 密码，如果没开启鉴权，则不需要
      port: 8020                            # 端口
      matchPathKeys: [ "flume" ]            # task-application 模块使用，调度平台日志 hdfs 路径关键字
      # kerberos
      enableKerberos: false
      # /etc/krb5.conf
      krb5Conf: ""
      # hdfs/*@EXAMPLE.COM
      principalPattern:  ""
      # admin
      loginUser: ""
      # /var/kerberos/krb5kdc/admin.keytab
      keytabPath: ""

  # task-metadata 模块配置依赖
  yarn:
    - clusterName: "bigdata"
      resourceManager: [ "ip:port" ] # yarn.resourcemanager.webapp.address 属性值
      jobHistoryServer: "ip:port" # mapreduce.jobhistory.webapp.address 属性值
  spark:
    sparkHistoryServer: [ "ip:port" ] # spark history ui 地址

compass
├── bin
│   ├── compass_env.sh                  环境变量，基础组件配置
│   ├── start_all.sh                    启动脚本
│   └── stop_all.sh                     停止脚本
├── conf
│   └── application-hadoop.yml          hadoop 相关配置
├── task-application                    关联任务实例、applicationId、hdfs_log_path
├── task-canal                          订阅调度平台 MySQL 表元数据到 Kafka
├── task-canal-adapter                  同步调度平台 MySQL 表元数据 Compass 平台
├── task-detect                         工作流层异常类型检测
├── task-metadata                       同步 Yarn、Spark 任务元数据到 OpenSearch
├── task-parser                         日志解析和 Spark 任务异常检测
├── task-portal                         异常任务的可视化服务
├── task-flink                          Flink 任务资源及异常诊断
├── task-flink-core                     Flink 任务诊断规则逻辑
├── task-portal                         异常任务的可视化服务
├── task-gpt                            聚合日志模板，并使用 chatgpt 给模板解决方案
└── task-syncer                         调度平台任务关系表的抽象和映射

LOAD DATABASE
     FROM mysql://root:password@localhost:3306/dolphinscheduler
     INTO postgresql://postgres@localhost:5432/compass
     ALTER SCHEMA 'dolphinscheduler' RENAME TO 'public'
     INCLUDING ONLY TABLE NAMES MATCHING 't_ds_process_definition','t_ds_process_instance','t_ds_process_task_relation','t_ds_project','t_ds_task_definition','t_ds_task_instance','t_ds_user';

LOAD DATABASE
     FROM mysql://root:password@localhost:3306/airflow
     INTO postgresql://postgres@localhost:5432/compass_airflow
     ALTER SCHEMA 'airflow' RENAME TO 'public'
     INCLUDING ONLY TABLE NAMES MATCHING 'task_instance','dag_run','ab_user','dag','serialized_dag'
     ALTER TABLE NAMES MATCHING 'task_instance' RENAME TO 'tb_task_instance'
     ALTER TABLE NAMES MATCHING 'dag_run'  RENAME TO 'tb_dag_run'
     ALTER TABLE NAMES MATCHING 'ab_user'  RENAME TO 'tb_ab_user'
     ALTER TABLE NAMES MATCHING 'dag'  RENAME TO 'tb_dag'
     ALTER TABLE NAMES MATCHING 'serialized_dag'  RENAME TO 'tb_serialized_dag';

curl "localhost:8181/etl/rdb/mysql1/t_ds_process_definition.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_process_instance.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_process_task_relation.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_project.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_task_definition.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_task_instance.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/t_ds_user.yml" -X POST

curl "localhost:8181/etl/rdb/mysql1/airflow_db_ab_user.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/airflow_db_dag_run.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/airflow_db_dag.yml" -X POST
curl "localhost:8181/etl/rdb/mysql1/airflow_db_task_instance.yml" -X POST

task-canal
├── bin
│   ├── compass_env.sh          compass 环境变量
│   ├── init_canal.sh           下载 canal.deployer 依赖包
│   ├── restart.sh
│   ├── startup.sh
│   └── stop.sh
├── canal.deployer-1.1.6.tar.gz  compass 不提供 canal 依赖包，可通过 init_canal.sh 下载，若无网络则自行下载到 task-canal 根目录
├── conf
│   ├── example
│   │   ├── instance.properties   源 MySQL 配置和库表配置
│   ├── canal_local.properties    zk, kafka 等配置
│   ├── canal.properties
│   ├── logback.xml
├── lib
└── plugin

canal.instance.master.address=localhost:33066
canal.instance.dbUsername=root
canal.instance.dbPassword=root
canal.instance.filter.regex=.*\..*
canal.mq.topic=mysqldata

# 动态 topic 和分区默认不配置，若数据量比较大，可按表 Hash 到相同 topic 不同分区，避免单分区压力过大
canal.mq.dynamicTopic = mysqldata:db\..*
canal.mq.partitionsNum =  12
canal.mq.partitionHash = .*\..*

canal.zkServers = localhost:2181
canal.serverMode = kafka
kafka.bootstrap.servers = localhost:9092

task-canal-adapter
├── bin
│   ├── compass_env.sh
│   ├── init_canal_adapter.sh       下载 canal.adapter 压缩包和解压相关 lib 和 plugin
│   ├── restart.sh
│   ├── startup.sh
│   └── stop.sh
├── canal.adapter-1.1.6.tar.gz      compass 不提供 canal 依赖包，可通过 init_canal.sh 下载，若无网络则自行下载到 task-canal-adapter 根目录
├── conf
│   ├── application.yml
│   └── rdb
│       ├── airflow_db_ab_user.yml
│       ├── airflow_db_dag_run.yml
│       ├── airflow_db_dag.yml
│       ├── airflow_db_task_instance.yml
│       ├── t_ds_process_definition.yml
│       ├── t_ds_process_instance.yml
│       ├── t_ds_process_task_relation.yml
│       ├── t_ds_project.yml
│       ├── t_ds_task_definition.yml
│       ├── t_ds_task_instance.yml
│       ├── t_ds_user.yml
│       └── template.yml
├── lib
└── plugin

canal.conf:
  srcDataSources:
    defaultDS:
      # Scheduling platform MySQL synchronization account
      url: ${CANAL_ADAPTER_SOURCE_DATASOURCE_URL}
      username: ${CANAL_ADAPTER_SOURCE_DATASOURCE_USERNAME}
      password: ${CANAL_ADAPTER_SOURCE_DATASOURCE_PASSWORD}

  canalAdapters:
  - instance: mysqldata # kafka topic
    groups:
    - groupId: g1
      outerAdapters:
      - name: rdb
        key: mysql1
        properties:
          # Compass platform datasource account
          jdbc.url: ${CANAL_ADAPTER_DESTINATION_DATASOURCE_URL}
          jdbc.username: ${CANAL_ADAPTER_DESTINATION_DATASOURCE_USERNAME}
          jdbc.password: ${CANAL_ADAPTER_DESTINATION_DATASOURCE_PASSWORD}

dataSourceKey: defaultDS
destination: mysqldata
groupId: g1
outerAdapterKey: mysql1
concurrent: false
dbMapping:
  database: ${SCHEDULER_MYSQL_DB}
  # 调度平台 MySQL 表
  table: example
  # compass 平台 MySQL 表
  targetTable: example
  # 主键配置
  targetPk:
    id: id
  mapAll: true
  commitBatch: 1

task-syncer
├── bin
│   ├── compass_env.sh
│   ├── startup.sh
│   └── stop.sh
├── conf
│   ├── application-airflow.yml
│   ├── application-dolphinscheduler.yml
│   ├── application.yml
│   └── logback.xml
├── lib

# DolphinScheduler 库名
- schema: "dolphinscheduler"
  # DolphinScheduler user 表
  table: "t_ds_user"
  # compass user 表
  targetTable: "user"
  # columnMapping 用于字段映射，key 是 compass 定义的字段，值是 DolphinScheduler 定义的字段
  columnMapping:
    user_id: "id"
    username: "user_name"
    password: "user_password"
    is_admin: "user_type"
    email: "email"
    phone: "phone"
    create_time: "create_time"
    update_time: "update_time"
  # 字段值映射, 目标字段值, 源字段值, 字段类型
  columnValueMapping:
    is_admin: [ { targetValue: "0", originValue: [ "0" ] }, { targetValue: "1", originValue: [ "1" ] } ]
  # 常量列定义
  constantColumn:
    scheduler_type: "DolphinScheduler"

- schema: "dolphinscheduler"
  table: "t_ds_task_instance"
  targetTable: "task_instance"
  columnMapping:
    id: "id"
    project_name: ""
    flow_name: ""
    task_name: "name"
    start_time: "start_time"
    end_time: "end_time"
    execution_time: ""
    task_state: "state"
    task_type: "task_type"
    retry_times: "retry_times"
    max_retry_times: "max_retry_times"
    worker_group: "worker_group"
    create_time: "create_time"
    update_time: "update_time"
  columnValueMapping:
    task_state:
      - { targetValue: "success", originValue: [ "7", "14" ] }
      - { targetValue: "fail", originValue: [ "6", "9" ] }
      - { targetValue: "other", originValue: [ "0", "1", "2", "3", "4", "5", "8", "10", "11", "12", "13" ] }
  columnDep:
    # 列字段值依赖，由于该表缺失了 project_name, flow_name, execution_time 字段，因此需要关联其他表查询
    columns: [ "project_name", "flow_name", "execution_time" ]
    queries: [ "select t2.schedule_time as execution_time, t3.name as flow_name, t4.name as project_name from t_ds_task_instance as t1 inner join t_ds_process_instance as t2 on t1.process_instance_id = t2.id inner join t_ds_process_definition as t3 on t2.process_definition_code = t3.code inner join t_ds_project as t4 on t3.project_code=t4.code where t1.id=${id}" ]

task-application/
├── bin
│   ├── compass_env.sh
│   ├── startup.sh
│   └── stop.sh
├── conf
│   ├── application-airflow.yml
│   ├── application-dolphinscheduler.yml
│   ├── application-hadoop.yml
│   ├── application.yml
│   └── logback.xml
├── lib

hadoop:
  namenodes:
    - nameservices: logs-hdfs
      namenodesAddr: [ "host1", "host2" ]
      namenodes: ["namenode1", "namenode2"]
      user: hdfs
      password:
      port: 8020
      matchPathKeys: [ "flume" ]
